Hobart Handler 210MVP MIG Welder

- Comfortable 10 ft. (3m) HR-100 gun
- Owner's manual with installation, operation and maintenance guidelines.
- 10 ft.(3m) work cable with clamp
- Built-in gas solenoid value and dual-gauge regulator with gas hose
- Spool hub assembly accommodates 4 or 8 in. spools
- Sample spool of .030 in. self-shielding flux-cored wire
- .030 (0.8mm) contact tips
- Quick Select drive roll for .024 in. (0.6 mm) or .030/.035 in.
- Power cord with 5-15 P (115 V, 15 A) and 6-50 P (230 V, 50 A) MVP (TM) plugs
- Welding guide and material thickness gauge

Max 210 amps in small portable case -
Sized for you to easily transport the unit to the jobsite with the power to weld 3/8 in. mild steel.

7 (230 V) and 4 (115V) voltage settings, with infinite wire feed speed control -
Allows you to fine control the output parameters for improved arc performance with less spatter for a better bead appearance and less clean up.

Accepts uncomplicated, simple-to-install direct plug-in SpoolRunner 100 spool gun -
Allows you to weld aluminum with enhanced feed ability and reduction of “bird-nesting.

Integrated spool gun control circuitry is standard -
Eliminates your need for an additional control box or adapter to connect the SpoolRunner 100 spool gun.

Dual-voltage capability with MVP (multi-voltage plug) -
Allows you to connect to common 115 or 230 V power receptacles without the use of any tools - simply choose the plug that fits the receptacle.

Door Chart with initial settings -
You are able to quickly reference initial settings for different wires, gases, materials, and thicknesses. Provides you a quick starting point whether you are a novice or professional.

Built-in contactor -
Keeps wire electrically “cold” until trigger is pulled which gives you ease of use and keeps you safe.

Industrial cast aluminum wire drive system -
Durable wire feed provides you professional performance

Convenient polarity changeover -
Easier and quicker for you to change polarity between solid or tubular wire.

Quick Select drive roll -
Less of your time consumed in setup by offering three grooves – two for different size solid wire and a third for flux-cored wire.

Short circuit protection -
Protects unit against current overload.

Self- resetting thermal overload protection -
Protects power transformer from thermal overload to provide you maximum reliability.

Current-limited motor protection -
Protects wire feed system from overload, you won’t need to change or reset the circuit breaker button.

Processes - Flux Cored (FCAW), MIG (GMAW)
Industries Interests - Racing / Customizing / Restoring, DIY / Home Hobbyist, Farm and Ranch, Metal Art, Manufacturing
Material Thickness - Mild Steel 24 ga. (0.5 mm) - 3/8 in. (9.5 mm)
Weldable Metals - Aluminum, Stainless Steel, Steel
Input Voltage - 110/115/120 V, 220/230/240 V
Input Phase - 1-Phase
Input Hz - 60 Hz
Current Type - DC
Rated Output - 115 V, 90A @ 20%,230V, 150A @ 30%
Max Open Circuit Voltage - 34 VDC
Wire Feed Speed - 40 IPM - 770 IPM
Wire Diameter - Stainless 0.024 in. - 0.035 in., Stainless 0.6 mm. - 0.9 mm., Solid Steel 0.6 mm. - 0.9 mm., Solid Steel 0.024 in. - 0.035 in., Flux Cored 0.03 in. - 0.045 in., Flux Cored 0.8 mm. - 1.2 mm.
Portability - Handle(s)
Weld Output - CV
Net Width - 10.625 in
Net Height - 12.375 in
Net Length - 19.5 in
Net Weight - 79 lbs
Warranty - 3 Years Hobart Warranty
