Hypertherm Powermax45 XP
The Powermax45 XP plasma cutter delivers increased cut capacity – up to 16 mm (5/8″) metal – as well as faster cut speeds, and automatic gas adjustment for quick, simple setup and operation. Duramax Lock torches support handheld and mechanized cutting of a wider range of metal thicknesses, along with precision gouging such as spot weld removal, and marking capabilities.
The Powermax45 XP plasma cutter delivers increased cut capacity – up to 16 mm (5/8″) metal – as well as faster cut speeds, and automatic gas adjustment for quick, simple setup and operation. Duramax Lock torches support handheld and mechanized cutting of a wider range of metal thicknesses, along with precision gouging such as spot weld removal, and marking capabilities.
The Powermax45 XP plasma cutter delivers increased cut capacity – up to 16 mm (5/8″) metal – as well as faster cut speeds, and automatic gas adjustment for quick, simple setup and operation. Duramax Lock torches support handheld and mechanized cutting of a wider range of metal thicknesses, along with precision gouging such as spot weld removal, and marking capabilities.
-
Applications - Drag cutting, Extended reach cutting, Extended reach gouging, Fine feature cutting, Flush cutting, Max control gouging, Mechanized cutting, Marking, Precision gouging
Easy to use
- One of our most compact and light weight systems, the Powermax45 XP is the ideal portable plasma cutter for a 16 mm (5/8") rated cutting system
- Patented drag-cutting technology makes the Powermax45 XP easy to use – even for first-time operators
- Smart Sense technology ensures that air pressure is always correctly set
Outstanding versatility
- CNC interface and FastConnect torch connection allows both handheld and mechanized operation
- A wide range of torch and consumable styles to choose from for both handheld and automated processes
- Extensive array of application capabilities via specialty consumables for fine feature cutting, extended reach cutting, gouging, precision gouging, and marking
Maximum productivity
- Finish jobs faster, with cut speeds 1.5 times greater than oxyfuel on 6 mm (1/4") mild steel
- Superior cut and gouge quality reduces time for grinding and edge preparation
- New torch disable switch feature allows faster, easier changeout of consumables
Rugged and reliable
- Duramax Lock torches are designed for high-impact and heat resistance
- SpringStart technology ensures consistent starting and optimum torch performance
- Hypertherm Certified™ reliability ensures peak performance even in the most demanding environments
Designed for low environmental impact
- Plasma cutting efficiency is 11% better than its predecessor, enabling you to cut more steel with less power, in less time
- All plasma system components are recyclable
- 14% lighter than its predecessor and delivers more cutting power -
Input voltages - (± 10%) 200–240 V, 1-PH, 50–60 Hz, 480 V, 3-PH, 50–60 Hz
Input current @ 65 kW - 200–240 V, 1-PH, 39/32 A, 480 V, 3-PH, 9.4 A
Output current - 10–45 A
Rated output voltage - 145 VDC
Duty cycle @ 104° F -
- 50% @ 45 A, 200–240 V, 1-PH
- 60% @ 41 A, 200–240 V, 1-PH
- 100% @ 32 A, 200–240 V, 1-PH
- 50% @ 45 A, 480 V, 3-PH
- 60% @ 41 A, 480 V, 3-PH
- 100% @ 32 A, 480 V, 3-PH
Open circuit voltage (OCV) - 275 VDC
Dimensions with handles - 17.4" D; 6.8" W; 14.1" H
Weight with 20' torch - 31 lbs.
Gas supply -
- Cutting: air (clean, dry and oil-free), nitrogen, F5
- Gouging: air (clean, dry and oil-free), nitrogen, F5
- Marking: air (clean, dry and oil-free), argon
Recommended gas inlet flow rate/pressure - 400 scfh @ 85 psi.
Input power cable length - 10'
Power supply type - Inverter – IGBT
Engine drive requirement - 12.5 kVA (10 kW) for full 45 A output
Electrical efficiency - 88%
Recyclability - 100%
Certifications - CSA-certified for use in the Americas and Asia, except China
Warranty - Power supply: 3-year Torch: 1-year
