Miller Millermatic 211 MIG Welder

- Millermatic 211
- Hook-and-loop cord wraps
- 6.5 ft (2 m) power cord and MVP™ adapter plugs for 120V and 240V
- 10 ft (3 m) MDX-100 MIG gun
- 10 ft (3 m) work cable and clamp
- Argon and AR/CO2 mix regulator/flow gauge with hose
- Spool of Hobart .030 in (0.8 mm) solid wire
- Two contact tips for .030 in (0.8 mm) wire
- Quick Select drive roll for .024 in (0.6 mm) or .030/.035 in (0.8/0.9 mm) solid wire, and .030/.035 (0.8/0.9 mm) flux cored wire
- Material thickness gauge #229895

Advanced Auto-Set -
Advanced Auto-Set now includes five different wire/gas combinations and .024, .030 and .035-inch wires. The easiest welder to use just became more versatile.

Inverter Technology -
Inverter technology combines best-in-class arc characteristics with the portability of a 38-pound machine. The arc is extremely forgiving to variations in arc length and travel speeds.

Quick Select Drive Roll -
Quick Select drive roll makes setup quicker by offering three grooves—two for different size solid wire and a third for flux-cored wire.

Auto Spool Gun Detect -
Auto Spool Gun Detect automatically detects when a MIG gun or spool gun is connected eliminating the need for a switch.

Fan-On-Demand -
Fan-On-Demand power source cooling system operates only when needed, reducing noise, energy use and the amount of contaminants pulled though the machine.

Multi-voltage plug (MVP) -
Multi-voltage plug (MVP) allows connection to common 120 or 240 V power receptacles without the use of any tools— simply choose the plug that fits the receptacle and connect to the power cord.

New Drive System -
Angled cast-aluminum drive system with calibrated tension knob creates consistent feeding and easy setup for up to 15-foot MIG guns.

Smooth-Start -
Smooth-Start provides a smooth, spatter-free start. It’s the best-starting machine in the small MIG machine category.

Generator Compatible -
The Millermatic 211 will be able to operate and provide full output when powered by generators with 7000 Watt (7K) output or higher, such as a Miller Bobcat or Trailblazer series generator. Limited output will occur when used with smaller generators.

Processes - MIG (GMAW)Flux Cored (FCAW)
Industries Interests - DIY / Home Hobbyist, Farm and Ranch, Metal Art, Racing / Customizing / Restoring, Education / Training
Amperage - 30A - 230A
Material Thickness - Aluminum 18 ga. (1.2 mm) - 3/8 in. (9.5 mm), Mild Steel 24 ga. (0.5 mm) - 3/8 in. (9.5 mm)
Weldable Metals - Aluminum, Stainless Steel, Steel
Input Voltage - 110/115/120 V, 220/230/240 V
Input Phase - 1-Phase
Input Hz - 50/60 Hz
Current Type - DC
Rated Output - 150 A at 21.5 VDC, 40% duty cycle (240V),115 A at 19.8 VDC, 20% duty cycle (120V)
Max Open Circuit Voltage - 54 VDC
Wire Feed Speed - 1.5 m/min - 15.2 m/min, 60 IPM - 600 IPM
Wire Diameter - Stainless 0.024 in. - 0.035 in., Stainless 0.6 mm. - 0.9 mm., Solid Steel 0.6 mm. - 0.9 mm., Solid Steel 0.024 in. - 0.035 in., Flux Cored 0.03 in. - 0.045 in., Flux Cored 0.8 mm. - 1.2 mm.
Spool Size - 8 in (203 mm)
Portability - Handle(s), Running Gear / Cart (Optional)
Weld Output - CV
Net Width - 11.25 in
Net Height - 12.5 in
Net Length - 20.5 in
Net Weight - 38 lbs
Warranty - 3 Years Miller's True Blue Warranty
