Miller Millermatic 255 MIG/Pulsed MIG Welder w/ EZ-Latch Running Gear- 208/240V

- Millermatic 255 with 10 ft. (3 m) power cord
- 15 ft. (4.5 m) 250-amp MDX-250 MIG gun w/ Bernard AccuLock S consumables for .035/.045 in. (0.9/1.2 mm) wire
- 10 ft. (3 m) work cable and clamp and 50mm Dinse-style connector
- Flow gauge regulator and gas hose for argon or AR/CO2 mix
- Extra contact tips
- .035/.045 in. (0.9/1.2 mm) reversible drive rolls
- Chain to secure gas cylinder
- Material Thickness Gauge
- EZ-Latch Running Gear

Easy-to-understand interface -
7-inch color LCD display ensures proper machine setup and parameter selection, reducing setup time and increasing weld time.

Pulsed MIG welding delivers higher quality -
Lower heat input for less distortion on thin materials, less spatter minimizes post weld grinding and rework allowing more welding time. Perform welding applications that couldn’t be done in the past.

Auto-Set Elite -
offers predefined weld settings to increase ease of use and ensure that the job is done right for operators of all skill levels.

Program mode allows easy save and recall of favorite weld settings -
Deliver more productivity, consistent quality by welders of all skill levels by using prequalified weld settings. Minimize supervisor need to intervene.

Auto-Line Technology -
For portability and reliability, this inverter power supply allows for any single-phase input voltage hookup (208–240 V) with no manual linking, providing convenience in any job setting. Ideal solution for dirty or unreliable power.

Versatility -
Capabilities include MIG, pulsed MIG and flux-cored welding.

MDX-250 MIG Gun w/ AccuLock S consumables -
AccuLock liner loads from the front and locks at the front and back to insure proper alignment for flawless wire feed path. New rubber overmold and ball -and-socket handle design improves grip and reduces welder fatigue. New Industrial Bernard AccuLock S contact tips provide superior Spray and Pulsed MIG arc performance

Portability - Machine only weighs 84 lb -
Weight is reduced by more than 50 percent compared to the Millermatic 252.

EZ-Latch running gear -
Operators no longer need to use lift truck to load machine and running gear into the truck. Latches secure machine to running gear. Simply loosen the latch retaining knob and rotate latches to disengage machine from running gear for easy portability.

Generator Compatible -
The Millermatic 255 will be able to operate and provide full output when powered by generators with 12000 Watt (12K) output or higher. Limited output will occur when used with smaller generators.

Processes - Aluminum Welding, Flux Cored (FCAW), MIG (GMAW)
Industries Interests - Auto Repair, Commercial Truck and Trailer, Construction, Education / Training, Fabrication, Farm and Ranch, Maintenance and Repair - In Plant, Manufacturing, Mechanical Contracting, Metal Art, Racing / Customizing / Restoring
Amperage - 20A - 350A
Material Thickness - Aluminum 18 ga. (1.2 mm) - 1/2 in. (12.7 mm), Mild Steel 24 ga. (0.5 mm) - 1/2 in. (12.7 mm)
Weldable Metals - Aluminum, Stainless Steel, Steel
Input Voltage - 208V, 220/230/240V
Input Phase - 1-Phase
Input Hz - 50/60 Hz
Input Amperage - 20-350
Current Type - DC
Rated Output - 230 A at 25.5 V, 60% duty cycle
Max Open Circuit Voltage - 87 VDC
Wire Feed Speed - 1.3 m/min - 20 m/min, 50 IPM - 800 IPM
Wire Diameter - Aluminum 0.035 in. - 0.047 in., Aluminum 0.9 mm. - 1.2 mm., Stainless 0.023 in. - 0.045 in., Stainless 0.6 mm. - 1.2 mm., Solid Steel 0.6 mm. - 1.2 mm., Solid Steel 0.023 in. - 0.045 in., Flux Cored 0.03 in. - 0.045 in., Flux Cored 0.8 mm. - 1.2 mm., Silicon Bronze 0.030 in. - 0.035 in., Silicon Bronze 0.8 mm - 0.9 mm.
Spool Size - 12 in (305 mm)
Portability - Handle(s), Running Gear / Cart (Standard)
Weld Output - CV
Warranty - 3 Years Miller's True Blue Warranty
